Indigenous EO/IR Systems (1 Viewer)

[Pundit Pikachu]

EO Payloads Brochure from Aero India 2023

EO Payloads for UAV Applications

LEOP (Light Weight Electro-Optical Payload)
Sensors - TI, SWIR, Colour CCD Camera & FLIR
Ball Diameter - 350 mm
Range - 7.5 Km
Weight - 35 kg

CAMOP (Compact Airborne Multi-sensor Optronic Payload)
Sensors - HD-TI, HD-SWIR, HD-CCD, ELRF, LLL TV, Laser Pointer & Illuminator
Ball Diameter - 450 mm
Range - 15 km
Weight - 55 kg

MREO (Medium Range Electro Optical Gimballed Payload)
Sensors - TI, Colour CCD Camera & LDRF
Ball Diameter - 450 mm
Range - 7.5 km
Weight - 60 kg

LREO (Long Range Electro Optical Gimballed Payload)
Sensors - TI, Colour CCD Camera & LDRF
Ball Diameter - 550 mm
Range - 40 km
Weight - 110 kg



[BHARAT KA BETA]

EO Payloads Brochure from Aero India 2023
View attachment 40344
EO Payloads for UAV Applications

LEOP (Light Weight Electro-Optical Payload)
Sensors - TI, SWIR, Colour CCD Camera & FLIR
Ball Diameter - 350 mm
Range - 7.5 Km
Weight - 35 kg

CAMOP (Compact Airborne Multi-sensor Optronic Payload)
Sensors - HD-TI, HD-SWIR, HD-CCD, ELRF, LLL TV, Laser Pointer & Illuminator
Ball Diameter - 450 mm
Range - 15 km
Weight - 55 kg

MREO (Medium Range Electro Optical Gimballed Payload)
Sensors - TI, Colour CCD Camera & LDRF
Ball Diameter - 450 mm
Range - 7.5 km
Weight - 60 kg

LREO (Long Range Electro Optical Gimballed Payload)
Sensors - TI, Colour CCD Camera & LDRF
Ball Diameter - 550 mm
Range - 40 km
Weight - 110 kg

Will any one of these variants be used in LCH, IMRH or any other Helicopter programs?



[Pundit Pikachu]

Proposed Laser Designation Pod (LDP) Brochure from Aero India 2023


• Detection, Recognition; Identification and Designation of Surface Targets
• Laser Sensor cum Targeting Pod used by aircrafts for day/night attack
• Accurate delivery of precision guided bombs
• Ability to transfer target Video and Pictures to base station



[Pundit Pikachu]

CAMOP Brochure from a technical seminar at Aero India 2023

Compact Airborne Multi-Sensor Optronic Payload (CAMOP)

Gimbal Configuration : 2 Axis, 4 Gimbal, Gyro Stabilized
Gimbal Freedom : Az : N × 360°, EL: +20° & -120°D
Dimension and Weight : ≤ 450mm × 600mm, ≤ 60kg
Payload : HD TI, HD SWIR, HD WFOV Colour Day camera, HD LLL TV cum Day spotter, ELRF, Laser -Illuminator & Pointer
Modes of Operation : Stabilization, Position, Scan, Track, Nadir
Recognition Range : Upto 40km for 180m × 10m target

Key features
• Stabilized, Compact, Multi Sensor Package
• Day, Night and Twilight operation with HD Payloads & Eye-safe laser range finder for target Ranging
• Target Illumination and Pointing using laser payloads
• Automatic Video tracker for target tracking & Geo-Pointing and Geo-location with Moving Map
• SuitabIe for 24×7 Surveillance and Reconnaissance Operation from Airborne Platforms

Status
• CAMOP is integrated on Tapas BH platform
• Five flight trials of CAMOP on TAPAS-BH conducted at ATR, Chitradurga


CAMOP Brochure from Defence Expo 2022 (Same Brochure was reused in Aero India 2023)

Specifications
The Compact Airborne Multi-sensor Optronic Payload (CAMOP) provides a stabilized line of sight (LOS) to perform surveillance, reconnaissance, target detection and automatic target tracking from airborne platform. This allows the LOS to be aimed and maintained stabilised in required orientation, independent of platform altitude and motions. The payload assembly possesses light weight (<60 kg) belly mount structure. The gimbal assembly houses eight EO sensors (5 Imaging sensors and 3 LASER sensors) within a ball diameter of 490 mm and weight less than 60 kg.

Features
• HD Medium Wave Infra-Red Camera
• HD Short Wave Infra-Red Camera
• HD Colour Day TV Camera
• HD Low Light Level CMOS Camera
• HD Spotter Scope (Camera)
• Laser Range Finder, Laser Pointer and Laser Illuminator

CAMOP images from Defence Expo 2022



CAMOP images from Aero India 2023




CAMOP images from Aero India 2025



[Pundit Pikachu]

LEOP Brochure from Aero India 2023

Light Weight Electro-Optical Payload for Helicopters and UAVs
Specifications
LEOP is a light weight modular two axis gyro stabilized electro-optical payload consisting of the state-of art sensors including Thermal Imager (Tl), Short Wave Infra-Red (SWIR) camera, CCD camera and Eye-safe Laser Range Finder (LRF). It is a light weight belly mounted structure. It provides a stabilized line of sight to perform the surveillance, reconnaissance, target detection and automatic tracking from airborne platform.

Features
• Stabilized multi sensor lightweight high accuracy gimbal
• Recognition ranges up to 11 Km for 7m x 2m target
• Day & Night operation
• Eye-safe Laser Range Finder for target ranging
• Automatic Target Tracking
• Single LRU solution with SWaP optimized configuration
• Configurable for airborne platforms like helicopter, UAV, Aerostat, Aircraft and security surveillance systems


LEOP images from Aero India 2023
