The BÚHOs are “Class I Electric Propulsion Unmanned Aerial Vehicle” type systems, intended for low-cost flight training, which allows the execution of operations with the necessary protocols to train SAMIRP operators in the tasks of takeoff, landing, short navigation, use of airborne sensors, failure mitigation and initial adaptation to operation in larger systems such as Class II; additionally, they allow tactical use adjusted to their performances.
They can also operate in principle with an autonomy of 40 minutes and a range of 10 km, from unprepared runways.
On September 27, 2021, the General Directorate of Research and Development (DGIyD) together with personnel from the Applied Research Center (CIA), began the process of delivering to the Chamical Military Air Base (BAM) dependent on the Training and Readiness Command, the Remotely Piloted Military Air Systems (SAMIRP) model AR-1F BÚHO together with their ground control systems, flight support and transfer containers.
Description:
Class I Electric Propulsion intended for low-cost flight training of operators and technicians.
It allows the execution of operations in takeoff, landing, short navigation tasks, use of airborne sensors, fault mitigation and initial adaptation for larger systems (Class II).
It supports Tactical use in surveillance, reconnaissance and intelligence (ISR) missions, adjusted to its performances.
It has the Fail-Safe function, which allows the aircraft to take control of the flight and navigation, previously programmed in the event of a loss of connection.
Structurally built in composite material, V-tail, with a high rectangular wing.
Technical specifications:
Weight: 30kg.
Height: 1mt.
Maximum range: 50km.
Payload: 2.4kg.
Payload (devices): FLIR (EO/IR) Gyro-stabilized
Speed: 60kts.
Powerplant: 6 HP- Electric
Maximum LOS data link distance: 60km
Engine: Brushless
Autopilot
Communications
Control type: RC-FVP-Automatic
Station type: Mobile / Tactical briefcase
Control link type: Expanded spectrum
Fuel type: LIPO batteries
They can also operate in principle with an autonomy of 40 minutes and a range of 10 km, from unprepared runways.
On September 27, 2021, the General Directorate of Research and Development (DGIyD) together with personnel from the Applied Research Center (CIA), began the process of delivering to the Chamical Military Air Base (BAM) dependent on the Training and Readiness Command, the Remotely Piloted Military Air Systems (SAMIRP) model AR-1F BÚHO together with their ground control systems, flight support and transfer containers.
Description:
Class I Electric Propulsion intended for low-cost flight training of operators and technicians.
It allows the execution of operations in takeoff, landing, short navigation tasks, use of airborne sensors, fault mitigation and initial adaptation for larger systems (Class II).
It supports Tactical use in surveillance, reconnaissance and intelligence (ISR) missions, adjusted to its performances.
It has the Fail-Safe function, which allows the aircraft to take control of the flight and navigation, previously programmed in the event of a loss of connection.
Structurally built in composite material, V-tail, with a high rectangular wing.
Technical specifications:
Weight: 30kg.
Height: 1mt.
Maximum range: 50km.
Payload: 2.4kg.
Payload (devices): FLIR (EO/IR) Gyro-stabilized
Speed: 60kts.
Powerplant: 6 HP- Electric
Maximum LOS data link distance: 60km
Engine: Brushless
Autopilot
Communications
Control type: RC-FVP-Automatic
Station type: Mobile / Tactical briefcase
Control link type: Expanded spectrum
Fuel type: LIPO batteries
