ISRO Project Surya: Next Generation Launch Vehicle (NGLV)

[Azaad]

A Lunar Fly by might be feasible with currently underdevelopment SOORY-H, with 30T LEO capability
View attachment 11391

View attachment 11393
SOORYA-SH with 70T LEO capability
View attachment 11396View attachment 11397

Top line of the 3rd SS reads 150 Tons LEO in Single Launch / Multiple Launches ( leave aside the multiple launches ) whereas Vision 2040 with the icon of the NGLV reads 70 tons. Why the discrepancy ?



[Anonymous Bharata]

Top line of the 3rd SS reads 150 Tons LEO in Single Launch / Multiple Launches ( leave aside the multiple launches ) whereas Vision 2040 with the icon of the NGLV reads 70 tons. Why the discrepancy ?

150t is for Single Launch Architecture and for moon base, they are currently pursuing dual launch architecture ( this is confirmed)
Dual launch is cheaper and requires less development time



[Anonymous Bharata]



[FalconSlayers]

Super Heavy Launch Vehicle plan of ISRO by 2040 (for landing Indian astronauts to the moon)



[Anonymous Bharata]

Super Heavy Launch Vehicle plan of ISRO by 2040 (for landing Indian astronauts to the moon)
View attachment 11411

A whitepill in the ocean of blackpills



[FalconSlayers]

A whitepill in the ocean of blackpills

Blackpill would be not getting built on time.



[Anonymous Bharata]

Blackpill would be not getting built on time.

It's better to expect delays, because space is not a easy business,but still a whitepill for me, I never thought we will be even thinking of landing our men & women on moon



[Pundit Pikachu]

Here's what we have learnt about NGLV and related variants from this recent presentation

Baseline NGLV
20 ton to LEO
9 ton to GTO

NGLV- H (NGLV with strap on solid boosters)
30 ton to LEO
12 ton to GTO

(I just wish ISRO use a bigger Solid booster, or increase the number of boosters to 4 and increase the LEO payload capacity to 35 tons, to allow us a comfortable Lunar flyby)


proposed NGLV-SH capable of delivering 70 tons to LEO


ISRO has also proposed a 150 ton to LEO capable super heavy Launch Vehicle for a future lunar transit capability


NGLV will be integrated horizontally and use a titable UT during launch (similar to what Space X uses)



[SlayingHell]

Here's what we have learnt about NGLV and related variants from this recent presentation
View attachment 11418
Baseline NGLV
20 ton to LEO
9 ton to GTO

NGLV- H (NGLV with strap on solid boosters)
30 ton to LEO
12 ton to GTO
View attachment 11419
(I just wish ISRO use a bigger Solid booster, or increase the number of boosters to 4 and increase the LEO payload capacity to 35 tons, to allow us a comfortable Lunar flyby)


proposed NGLV-SH capable of delivering 70 tons to LEO
View attachment 11424

ISRO has also proposed a 150 ton to LEO capable super heavy Launch Vehicle for a future lunar transit capability
View attachment 11422

NGLV will be integrated horizontally and use a titable UT during launch (similar to what Space X uses)
View attachment 11425

more number of boosters like 4 means they can't be integrated horizontally and erected. Hence only 2 are possible side by side.



[TopWatcher]

Issue when will these come to realty!



[Anonymous Bharata]

Here's what we have learnt about NGLV and related variants from this recent presentation
View attachment 11418
Baseline NGLV
20 ton to LEO
9 ton to GTO

NGLV- H (NGLV with strap on solid boosters)
30 ton to LEO
12 ton to GTO
View attachment 11419
(I just wish ISRO use a bigger Solid booster, or increase the number of boosters to 4 and increase the LEO payload capacity to 35 tons, to allow us a comfortable Lunar flyby)


proposed NGLV-SH capable of delivering 70 tons to LEO
View attachment 11424

ISRO has also proposed a 150 ton to LEO capable super heavy Launch Vehicle for a future lunar transit capability
View attachment 11422

NGLV will be integrated horizontally and use a titable UT during launch (similar to what Space X uses)
View attachment 11425

One more interesting thing about this project is we are getting our 2nd true indigenous liquid engine.

Vikas,CE-7.5 & SCE-200 are derivatives of foreign engines, only CE-20 is indigenous design , now LME-1100 will join the indigenous engine list. With this we will become fully indigenous in spaceflight



[Aaj Ka Hero]

I hope they go straight for super heavy 150 ton version instead of 70 ton, will multi-fold increase India space lifting capability as well as amount of important equipments we can put in space.

Let's aim for top position, what's with always REASONABLE, ACCORDING TO BUDGET SHIT, just for this once, act wild GOI.



[Anonymous Bharata]

I hope they go straight for super heavy 150 ton version instead of 70 ton, will multi-fold increase India space lifting capability as well as amount of important equipments we can put in space.

Let's aim for top position, what's with always REASONABLE, ACCORDING TO BUDGET SHIT, just for this once, act wild GOI.

It's not just budget, its about engine & materials,this is first time for us to design an indigenous 1000KN thrust engine, all earlier engines except CE-20 are of foreign designs. We cannot jump straight to a 3000KN Full flow Staged Combustion engine from a 200KN Gas generator engine design, that too even before mastering the Oxidiser rich staged combustion cycled SCE-200 semicryo engine. If we go that route, we will fall flat just like in Kaveri's case.



[Aaj Ka Hero]

It's not just budget, its about engine & materials,this is first time for us to design an indigenous 1000KN thrust engine, all earlier engines except CE-20 are of foreign designs. We cannot jump straight to a 3000KN Full flow Staged Combustion engine from a 200KN Gas generator engine design, that too even before mastering the Oxidiser rich staged combustion cycled SCE-200 semicryo engine. If we go that route, we will fall flat just like in Kaveri's case.

So, they are going to convert SCE-200 engine for methalox use right?



[Pundit Pikachu]

Intresting thread by Indranil Roy on Why NGLV uses a cluster of 9 engines and went for a 3 stage design instead of the more conventional 2 stage approach


View: https://x.com/Indrani1_Roy/status/1752059713641120186

Thread by @Indrani1_Roy on Thread Reader App

@Indrani1_Roy: For me, NGLV is the most exciting developments from ISRO. Enough info has trickled out to make some educational guesses. Thank you @TitaniumSV5 for capturing the slide Dr. V. Narayanan, Director, LPSC...…

threadreaderapp.com



[Anonymous Bharata]

So, they are going to convert SCE-200 engine for methalox use right?

No, 3000KN Methalox engine will be a clean sheet new design

SCE-200 is Oxidiser rich staged combustion
3000KN methalox currently under conceptual study phase will be Full Flow Staged Combustion like SpaceX raptor

& 1100KN thrust LME-1100 currently under development will be a gas generator cycle engine like CE-20



[Pundit Pikachu]

Here's what we have learnt about NGLV and related variants from this recent presentation
View attachment 11418
Baseline NGLV
20 ton to LEO
9 ton to GTO

NGLV- H (NGLV with strap on solid boosters)
30 ton to LEO
12 ton to GTO
View attachment 11419
(I just wish ISRO use a bigger Solid booster, or increase the number of boosters to 4 and increase the LEO payload capacity to 35 tons, to allow us a comfortable Lunar flyby)


proposed NGLV-SH capable of delivering 70 tons to LEO
View attachment 11424

ISRO has also proposed a 150 ton to LEO capable super heavy Launch Vehicle for a future lunar transit capability
View attachment 11422

NGLV will be integrated horizontally and use a titable UT during launch (similar to what Space X uses)
View attachment 11425

More details about the 150 ton to LEO capable Super Heavy Rocket's Engine, (from an older presentation) it will be a 3000KN Full Flow Staged Combustion Engine (based on Learnings from the SCE 200)

View: https://x.com/nssdatta/status/1843214736630100403



[Aaj Ka Hero]

Once upon a time, soviet were building full staged engine with the name of rd-270, which was going to give 670 tons of thrust, much bigger than isro proposed 300 tons engine or even that raptor.
It was way back in 70s though.



[Anonymous Bharata]

SOORYA's first stage LM450 static test will be done at Third Launch Pad itself, not at IPRC, they will initially do RTLS (retvrn to launch site) recoveries

Isro To Build 3rd Launch Pad, New Generation Launch Vehicle (NGLV) Could Also Land On Sea

With India’s space mission expanding both in size and vision, the Indian Space Research Organisation (Isro) is all geared up for the establishment of the third launch pad at its spaceport in Sriharikota. The new pad will not only serve as redundancy for the second launch pad to begin with but is...

timesofindia.indiatimes.com



[Anonymous Bharata]

View: https://x.com/indianspacepost/status/1843312593399881912
